Galvanized Steel Plate

Galvanized steel is typically used where corrosion resistance is required, painting is not required, and it is easy to drill, form and weld. ZongXiang can provide sizing and cutting services according to customer requirements. As a low-cost alternative to stainless steel, galvanized steel can provide rust protection for 20 years or more.

[email protected]

Share    

Description

Advantages

We offer different grades of galvanized steel sheet for various applications, the quality of the steel layer, the quantity and composition of the zinc coating and the subsequent chemical conversion coating are specially designed to provide the best performance for each application.

Characteristics of galvanized steel Plate

Environmentally friendly, completely free of chromate.
Excellent corrosion resistance. By controlling the amount of galvanizing, the galvanized layer on the steel plate is covered evenly. The galvanized layer itself is chemically treated to ensure corrosion resistance.
The surface of galvanized steel sheet is smooth and uniform, which ensures good machinability, paintability and weldability.
The product has a wide range of uses, including residential, industrial buildings, automobiles, electrical appliances, etc. Suitable for: roofs, building panels, interior and exterior wall panels, lighting installations, etc.

Steel Plate Specifications

Unit weight (kg/piece)	Dimensions (a x b)				Galvanized quantity
Thickness (t) (mm)	914 x 1829mm	914 x 2134mm	1219 x 2438mm	1524 x 3048mm
	( 3’x 6’)	( 3’x 7’)	( 4’x 8’)	( 5’x 10’)
0.11		2.04
0.35	5	5.83	8.89	13.9	Z18
0.4	5.66	6.6	10.1	15.7	Z18
0.45		7.37	11.23		Z18
0.5	6.97	8.13	12.4	19.4	Z18
0.6	8.39	9.78	14.9	23.3	Z22
0.7		11.31	17.24		Z22
0.8	11	12.8	19.6	30.6	Z22
0.9			21.9		Z22
1	13.6	16.1	24.2	37.9	Z22
1.2	16.4	19.1	29.1	45.5	Z27
1.4	19	22.2	33.8	52.8	Z27
1.5	20.32	23.7	36.13	56.47	Z27
1.6	21.6	25.2	38.5	60.1	Z27
2	26.9	31.4	47.8	74.7	Z27
3	40.01	46.68	71.12	111.16	Z27
4	53.1	62	94.5	148	Z27
4.5	59.7	69.6	106	166	Z27
